Victron BlueSolar PWM-Pro 12/24V-20A Charge Controller

The Victron BlueSolar PWM-Pro charge controller is engineered to efficiently manage the charging and discharging processes of solar power systems, ensuring optimal battery performance. Featuring Victron Energy’s advanced technology, this charge controller effortlessly supports both 12V and 24V systems, automatically detecting system voltage. Built with safety and user-friendliness in mind, the device provides a range of protections and operational modes tailored to enhance battery life and solar panel effectiveness.

Product Features

Adaptive Load Output Management

This charge controller includes a load output with a low battery voltage disconnect function, ensuring the longevity and reliability of your setup by preventing battery over-discharge. The Victron Energy SCC010020110 is designed to adaptively manage energy distribution, enhancing system resilience.

Easy Timer-Controlled Lighting

Featuring a straightforward lighting control function with an integrated timer, users can easily set their lighting schedules for optimal energy usage, providing convenience and tailored illumination periods without complexity.

Intuitive Display Interface

Equipped with a two-digit seven-segment display, the controller offers a user-friendly setup experience. This display allows for quick adjustments of load output functionalities, including precise timer settings, facilitating efficient operation and configuration.

Three-Stage Battery Charging

Experience efficient energy management with the three-stage battery charging process: bulk, absorption, and float. Although not programmable, this feature ensures batteries are charged optimally, enhancing their lifespan and performance in both everyday and demanding usage scenarios.

Robust Protection Features

Designed for system integrity, the charge controller is protected against overloads, short circuits, and reverse polarity connections, ensuring safe and reliable operations across diverse environment conditions. These robust features contribute to the Victron Energy SCC010020110’s durability and dependability.

How It Works

The Victron BlueSolar PWM-Pro charge controller operates by managing the flow of electricity from solar panels to batteries, utilizing advanced algorithms for precise charge control across various stages. Its components work in unison to guarantee efficient solar energy management with minimal maintenance needs.

Smart Voltage Detection

This controller’s automatic system voltage detection feature simplifies setup by instantly adapting to the connected system, whether it’s a 12V or 24V configuration, contributing to seamless integration and enhanced solar energy harnessing.

Protective Load Management

With its automatic load disconnect capability, the controller safeguards batteries against deep discharges. This feature is essential for maintaining battery health and extends the utility of the stored energy within the system.

Thermal and Overload Safety

Equipped to handle varied environmental conditions, this component includes overload protection and immediate short circuit shutdowns, enhancing system safety and reliability by preventing damage under extreme usage.

Specifications

Battery Voltage	12/24 V with automatic system voltage detection
Rated Charge Current	5A / 10A / 20A / 30A
Automatic Load Disconnect	Yes
Maximum Solar Voltage	28V / 55V
Self-consumption	< 10 mA
Operating Temperature Range	-20 to +50°C
Humidity	Max 95% (non-condensing)
Protection Class	IP20
Dimensions	70 x 133 x 33.5 mm
Weight	0.15 kg / 0.2 kg
