Victron BlueSolar PWM-LCD&USB 12/24V-10A Charge Controller

The Victron Energy SCC010010050 is a versatile charge controller designed to optimize battery charging from solar panels. This device is ideal for maintaining battery health over time through its intelligent charge management, ensuring users can depend on efficient energy storage and use. It is specifically engineered to provide robust protection against overcharging and misconnected batteries, making it a dependable choice for both residential and light commercial solar systems.

Product Features

Advanced Battery Charging

Featuring a three-stage charging process, including bulk, absorption, and float, the Victron Energy SCC010010050 enhances battery life and efficiency by adjusting the charge as needed, maintaining optimal performance.

Integrated Protection Measures

This controller is equipped with safeguards against overcurrent, short circuits, and incorrect battery connections, minimizing risks and ensuring safe, uninterrupted operation of your solar power system.

Automatic Low Voltage Disconnect

With its intelligent load disconnect function, the controller prevents excessive battery discharging by automatically managing power flow based on voltage readings, thus protecting your battery investment.

User-Friendly Interface

The intuitive two-digit seven-segment display allows for straightforward setup and monitoring of system status, simplifying operation for users of all technical skill levels.

Flexible Load Control

Supports both automatic and manual load control options, offering users flexibility in managing power outputs according to specific needs or conditions.

How It Works

This charge controller efficiently converts solar energy to charge batteries, while simultaneously regulating the output to prevent overcharging and deep discharge. Its sophisticated circuitry automatically detects system voltage and adjusts its operation to enhance battery life and reliability.

Programmable Load Output

This component allows for setting load outputs with various timed settings, enhancing control over energy use by automatically turning on the connected device at dusk and off after a pre-set duration.

Reverse Polarity Protection

Ensures the safety of the system by preventing damage in case the battery or solar panel connections are accidentally reversed.

High Efficiency Operation

Designed for minimal self-consumption, this controller maximizes the solar energy that is captured and utilized, improving the overall efficiency of the solar setup.

Specifications

Battery Voltage	12/24V with automatic system detection
Rated Charge Current	10A
Recommended Solar Array	36 cell for 12V / 72 cell for 24V
Maximum Solar Voltage	28V for 12V system, 55V for 24V system
Self-consumption	< 10mA
Operating Temperature Range	-20 to +50°C
Protection Class	IP20
Terminal Size	5 mm² / AWG10
Weight	0.13 kg
Dimensions (h x w x d)	70 x 133 x 33.5 mm
