Victron BlueSolar MPPT 100/30 Charge Controller

Introducing the Victron Energy SCC020030200, a state-of-the-art solar charge controller designed to maximize your solar panel’s efficiency. Utilizing Maximum Power Point Tracking (MPPT) technology, this device enhances energy capture, particularly in fluctuating light conditions. Its advanced features offer superior protection and user programmability, ensuring optimal performance and longevity for your solar power setup.

Product Features

Ultra-Fast MPPT Technology

With ultra-fast Maximum Power Point Tracking, the Victron BlueSolar maximizes energy collection by up to 30% compared to PWM controllers and by 10% over slower MPPT models, especially in changing lighting situations.

Advanced Power Point Detection

This controller features advanced power point detection that finds the optimal power point, even in partial shading conditions, ensuring you always benefit from maximum energy harvest.

High Conversion Efficiency

Achieving efficiencies above 98%, this controller surpasses traditional models, operating without a cooling fan and providing full output current maintenance up to 40°C (104°F).

Customizable Charge Algorithm

The device offers a fully programmable charge algorithm with eight pre-set options, enabling easy customization via a simple rotary switch for enhanced charging effectiveness.

Comprehensive Protection

This charge controller ensures electronic protection with features such as over-temperature power derating, PV short circuit protection, reverse polarity safeguards, and an internal temperature sensor.

How It Works

The Victron BlueSolar MPPT controllers work by constantly monitoring your solar system€™s inputs and optimizing the electricity supplied to your batteries. This system uses advanced algorithms to ensure that it adapts even in partial shading situations, maximizing energy efficiency without user intervention.

Real-Time Data Display

Stay informed with real-time data available on Apple and Android devices via the VE.Direct to Bluetooth Smart dongle, or through the ColorControl panel.

Intelligent Temperature Sensor

The integrated sensor adjusts the absorption and float charge voltage according to temperature variations to optimize battery performance and lifespan.

Advanced Safety Features

The controller is equipped with crucial safety features such as over-temperature protection and a derating feature to prevent overheating, maintaining device integrity under demanding conditions.

Specifications

Battery Voltage	12/24V Auto Select
Rated Charge Current	30A / 50A
Nominal PV Power, 12V	440W / 700W
Nominal PV Power, 24V	880W / 1400W
Maximum PV Open Circuit Voltage	100V
Max. PV Short Circuit Current	35A / 60A
Maximum Efficiency	98%
Self-Consumption	10 mA
Charge Voltage ‘Absorption’	14.4V / 28.8V (adjustable)
Charge Voltage ‘Float’	13.8V / 27.6V (adjustable)
Operating Temperature	-30 to +60°C
Protection Category	IP43 (electronic), IP22 (connection)
Weight	1.3 kg
Dimensions (h x w x d)	130 x 186 x 70 mm
