SolarEdge SEACTL-1250-300-C3

The SolarEdge SEACTL-1250-300-C3 is designed for commercial applications, providing high accuracy measurements essential for energy monitoring. This reliable unit ensures revenue-grade data collection while being easy to install in standard electrical panels. Ideal for utility and commercial installations, it supports diverse operational needs and offers versatile communication options.

Product Features

High Accuracy Measurements

This meter is engineered to deliver precise revenue-grade readings, facilitating accurate energy monitoring. The SolarEdge SE-RWND-3D-480-MB guarantees 1% accuracy, ensuring reliable data for energy management and billing purposes.

User-Friendly Installation

Designed for simplicity, this meter can be easily mounted within standard electrical panels. Its compact dimensions make the SolarEdge SE-RWND-3D-480-MB perfect for various installation environments, minimizing setup time and effort.

Versatile Communication Options

The SolarEdge Three Phase Revenue Grade Meter supports RS485 communication, enabling seamless data transmission for monitoring and analysis. It features a 120AŽ© line termination, enhancing overall communication integrity across the system.

Robust Environmental Compliance

This meter adheres to rigorous safety and emission standards, including IEC and ANSI specifications, ensuring steadfast operation in various conditions while maintaining compliance for commercial usage.

Flexible Power Support

Operating across a voltage range of 208-480 Vac, the SolarEdge SE-RWND-3D-480-MB supports a wide array of commercial applications, making it an adaptable solution for various energy monitoring needs.

How It Works

The SolarEdge Three Phase Revenue Grade Meter works by continuously measuring electrical parameters and communicating this information through its advanced RS485 interface. This functionality enables real-time monitoring and efficient data collection.

Electrical Measurement Functionality

This component manages all electrical readings, providing essential data, such as voltage, current, and frequency, ensuring accurate performance tracking of the electrical system.

Communication Interface

The RS485 communication interface allows for effective data exchange between the meter and external monitoring systems, facilitating detailed analysis of energy consumption.

Compliance and Safety Mechanisms

The meter features built-in safety mechanisms that adhere to relevant standards, ensuring safe operation and reliable performance in diverse commercial settings.

Specifications

Model	SE-RWND-3D-480-MB
Operating Voltage Range	480 Vac
AC Frequency	60 Hz
Power Consumption	1.8 W
Supported Communication	RS485
Dimensions (HxWxD)	6.02 Aƒ— 3.35 Aƒ— 1.50 in.
Weight	11 Lb.
Environmental Rating	Indoor/Outdoor (with proper enclosure)
Operating Temperature Range	-40 to 167 °F
Relative Humidity	5 – 90 % (non-condensing)
Standards Compliance	IEC 61010-1, ANSI C12.20
