Quick Mount The roof-mount JayBox comes with a JayBox a flashing and two deck screws. – QM-JBX-RF02-B1
MPN Number:
Quick Mount JayBox Roof-Mounted Junction Box
The Quick Mount QM-JBX-RF02-B1 is a reliable junction box designed for easy roof installation, providing efficient protection for your photovoltaic system. This durable product is crafted from high-strength materials to ensure weather resistance and longevity, making it a perfect addition to any solar setup. Ideal for both rail and deck installations, it features QuickMount’s Elevated Water Seal Technology for excellent waterproofing, safeguarding roof penetrations efficiently.
Product Features
Comprehensive Flashing Protection
Included in the Quick Mount JayBox is an effective flashing system with a raised design that perfectly integrates with an EPDM sealing gasket. This assures optimal protection of roof penetrations, showcasing its superior weatherproof capabilities.
Convenient Hinged Lid
The JayBox is equipped with a detachable, hinged lid that simplifies access and reduces interference during maintenance or installation, even on steep roof slopes of up to 70.
Easy Drill and Drain Design
Benefiting from user-friendly drilling guides, the enclosure facilitates quick and effortless installation, while incorporated weep holes mitigate condensation inside the box.
High Standards Certification
Having passed both the UL 441 Section 27 “Rain Test” and the TAS 100-95 “Wind-Driven Rain Test,” the JayBox confirms its superior water resistance and durability.
Sturdy Construction Material
Crafted from robust NORYL resin, this junction box exhibits excellent durability and high-temperature stability, ensuring long-lasting performance and reliability.
How It Works
This junction box operates as both a functional and protective element of solar installations, combining robust materials and advanced design to safeguard and optimize electrical connections.
Efficient Rail Installation
The JayBox easily integrates with existing rail systems, using provided hangers and fasteners, simplifying the setup process for installers.
Innovative Deck Installation
Its deck-mounted configuration employs provided flashing and screws, ensuring secure attachment to shingle roofs and excellent weatherproofing.
Waterproof Pass-Through Design
Enabling safe passage of cables from the junction box into the attic, the design ensures protection against water ingress, maintaining the integrity of electrical connections.
Specifications
| Maximum System Voltage | 1500V |
| Maximum Current (Isc) | 100A |
| Maximum Current per Circuit (String) | 30A |
| Ambient Operating Conditions | -40C to 75C |
| Enclosure Rating (NEMA) | Type 3R – Rainproof |
| Allowable Wire Inputs | 12 – 10 AWG |
| Allowable Wire Outputs | 12 – 8 AWG |
| Equipment Grounding Conductor | 10 – 6 AWG |
| Material | NORYL Resin |
| Certified Testing | UL 1741 by Intertek Group plc |
