Philadelphia Solar 108 Half Cells Black/Black 440w Solar Panel

The Philadelphia Solar PS-MNB108-(HCBF)-440W is a premium photovoltaic module engineered for maximum energy efficiency and durability. With a power output of 440 W and a sleek black-on-black design, this panel is ideal for residential and commercial applications, combining aesthetics with performance.

Product Features

High Efficiency

Featuring advanced half-cell technology, the Philadelphia Solar PS-MNB108-(HCBF)-440W achieves superior energy conversion efficiency, delivering consistent and reliable power output.

Durable Design

The module is built with a robust tempered glass and aluminum alloy frame to withstand harsh weather conditions, including heavy snow loads and strong winds.

Optimized Performance

Equipped with anti-reflective coating and PERC technology, this solar panel enhances light capture and minimizes energy losses for optimal power generation.

Environmentally Friendly

Designed with sustainable manufacturing practices, the Philadelphia Solar PS-MNB108-(HCBF)-440W aligns with global green energy standards, ensuring low environmental impact.

Extended Warranty

Enjoy peace of mind with a 25-year performance warranty, guaranteeing high energy output throughout the lifespan of the panel.

How It Works

Half-Cell Technology

The Philadelphia Solar PS-MNB108-(HCBF)-440W 108 half-cell configuration minimizes resistance and increases energy efficiency, especially under partial shading conditions.

Monocrystalline PERC Cells

High-purity monocrystalline PERC cells ensure exceptional power generation by Philadelphia Solar PS-MNB108-(HCBF)-440W, even in low-light environments.

Smart Junction Box

The IP68-rated junction box offers excellent protection against dust and water ingress, ensuring reliable electrical performance.

Specifications

Model Number	PS-MNB108-(HCBF)-440W
Nominal Power (Pmax)	440 W
Module Efficiency	20.5%
Optimum Operating Voltage (Vmp)	41.2 V
Optimum Operating Current (Imp)	10.68 A
Open Circuit Voltage (Voc)	49.5 V
Short Circuit Current (Isc)	11.18 A
Dimensions	1765 × 1048 × 35 mm
Weight	21.5 kg
Cell Type	Monocrystalline PERC
Frame	Anodized Aluminium Alloy
Glass	3.2 mm Tempered, Anti-Reflective Coating
Operating Temperature	-40°C to +85°C
Max System Voltage	1500 V DC
Warranty	25 Years Performance Warranty

Certification

This product meets international safety and performance standards, ensuring reliable operation and energy output.
