Outback Power 2.3kW 48VDC 230VAC Sealed Mobile & Marine Inverter/Charger – FX2348EMT
MPN Number:
Outback Power 2.3kW 48VDC 230VAC Sealed Mobile & Marine Inverter/Charger – FX2348EMT
The Outback Power FX2348EMT offers robust power conversion solutions, delivering true sinewave power with advanced battery charging technology. This modular and expandable inverter/charger is designed for mobile and marine applications, ensuring consistent power output and efficient battery management. Perfect for sensitive electronic devices, it guarantees minimal interference and reliable surge power for demanding loads.
Product Features
True Sinewave Output
Experience clean and efficient power delivery with the true sinewave output of the FX2348EMT, ideal for running sensitive electronics without harmonic distortion.
Advanced Battery Charging
With intelligent battery charging, this model prolongs battery life while optimizing performance, making it efficient and reliable for continuous use.
Modular and Stackable Design
The modular design allows the system to grow with your power needs, ensuring scalability and future-proofing for diverse applications.
Weather-Resistant and Durable
Built with a weather-resistant sealed chassis and corrosion-resistant components, the FX2348EMT is designed for longevity and durability in harsh environments.
Integrated Network Communications
Benefit from integrated network communications that enable seamless coordination and control over your power systems, enhancing usability and functionality.
How It Works
The FX2348EMT inverter/charger combines three essential power functions: DC to AC inversion, battery charging, and automatic AC transfer switching. This comprehensive system ensures minimal interruption in power supply, making it a versatile solution for various power management needs.
DC to AC Inversion
Transforms DC power from batteries into clean AC power for electronics, reducing noise and interference during operation.
Efficient Battery Charging
Uses power factor-corrected technology to maximize charging efficiency, utilizing shore power and generators effectively.
AC Transfer Switching
Seamlessly switches between shore power and generator inputs, maintaining power stability without dropping loads.
Specifications
| Nominal DC Input Voltage | 48 Vdc |
| Continuous Power Rating at 25C (77F) | 2300 VA |
| AC Voltage/Frequency | 230 Vac / 50 Hz |
| Continuous AC RMS Output at 25C (77F) | 10.0 Aac |
| Idle Power Full | ~ 23 Watts |
| Typical Efficiency | 93% |
| Total Harmonic Distortion – Typical | 2% |
| Output Voltage Regulation | 2% |
| Maximum Output Current – Peak | 35 Aac |
| AC Overload Capability Surge | 5750 VA |
| Operating Temperature Range | -40 to 60C (power derated above 25C) |
| Continuous Battery Charger Output | 35 Adc |
| Warranty | Standard 5-year Warranty |
| Weight (lbs/kg) – Unit | 62.2 / 28.4 |
| Dimensions H x W x L (in/cm) | 13 x 8.25 x 16.25 / 33 x 21 x 41 |
