Outback Power EnergyCell 810Ah 24VDC High Capacity VLRA-AGM Battery – 800RE-24
MPN Number:
Outback Power EnergyCell 810Ah 24VDC High Capacity VLRA-AGM Battery
The Outback Power 800RE-24 is an advanced battery solution designed for applications requiring dependable power storage. Featuring cutting-edge VRLA-AGM technology, this battery offers superior performance with minimal maintenance needs. It is engineered to deliver extended cycle life and robust energy storage for both grid-interactive and independent renewable energy systems.
Product Features
Enhanced Cycle Durability
The battery boasts a remarkable 1800 cycles at 50% depth of discharge, providing long-lasting energy solutions for demanding environments while using the Outback Power 800RE-24.
Compact System Design
Optimizing space utilization, the 800RE-24 features a 4A6 standard system configuration, which facilitates easy installation in constrained areas, enhancing usability.
Optimal Heat Dissipation
Its frame design maximizes heat dissipation, ensuring stable performance and durability, a key feature of the Outback Power 800RE-24.
Maintenance-Free Operation
Leveraging VRLA-AGM technology, the battery offers 99% gas recombination, negating the need for periodic watering or terminal tightened, making maintenance frustrations a thing of the past.
Steel-Can Construction
With integral racking and a robust steel-can casing, the 800RE-24 provides a reliable battery solution with quick setup and sturdy construction to enhance product utilization.
How It Works
This battery operates through a modular design utilizing VRLA-AGM technology, enhancing performance through advanced materials and precise cell construction. Its innovative design enables efficient power flow and superior energy storage capabilities.
Cell Design Technology
Utilizing Absorbed Glass Mat (AGM) cells, it features thicker positive plates for extended battery life, ensuring each charge delivers maximal power.
Sealed Construction
The dual-post, welded, epoxy-sealed design ensures industry-leading battery casing integrity, crucial for maintaining performance under rigorous conditions.
Copper Post Efficiency
Its large copper post design significantly enhances high-rate performance, maximizing energy delivery efficiently and reliably.
Specifications
| Nominal Voltage Per Cell | 2V |
| Nominal Voltage Per System | 24VDC / 48VDC |
| Cycle Life (50% DOD) | 1800 cycles |
| Absorb Voltage | 55.6VDC |
| Float Voltage | 54VDC |
| Equalize Voltage | 2.32VDC |
| Maximum Charge Current | 148.75A |
| Operating Temperature Range | -4 to 122F (-20 to 50C) |
| Optimal Operating Temperature | 68 to 86F (20 to 30C) |
| Weight | 2262 lb (1189.3 kg) |
| Self-Discharge Time | 6 months @ 25C |
