Emmvee 395W Black On Black 72 Cell Mono Solar Panel – E395M72-B

The Emmvee E395M72-B is a robust solar panel designed for exceptional performance, even in the most challenging weather conditions. Featuring cutting-edge technology, this module offers remarkable efficiency with a rated power of 395W. Constructed with high-quality Mono PERC cells, it ensures long-lasting energy solutions while promoting sustainable living. Perfect for on-grid solar power plants, the E395M72-B supports contemporary energy needs with durability and reliability.

Product Features

AR Coated High Transmission Glass

Incorporating advanced AR coating technology, the Emmvee E395M72-B enhances light absorption and minimizes reflection losses, effectively improving the module€™s overall efficiency, especially under weak light conditions.

High Anodised Aluminium Frame

The robust high anodised aluminium frame ensures structural integrity and corrosion resistance, enabling the panel to withstand high snow and wind loads, ensuring reliability over the module’s lifespan.

PID Free Performance

Engineered to deliver PID-free performance, this module maintains optimal electrical power output, minimizing degradation and securing the module’s ability to produce consistent energy, even in extreme conditions.

Mechanical Load of 5400 Pa

Designed to endure a mechanical load of up to 5400 Pa, the module guarantees stability and durability, making it resistant to high pressure caused by environmental factors such as snow or wind.

MC4 Compatible Connectors

The inclusion of MC4 compatible connectors facilitates secure and efficient connections, ensuring ease of installation and optimizing energy transfer for maximum system performance.

How It Works

The operation of the Emmvee E395M72-B solar panel revolves around its high-efficiency Mono PERC cells, which convert sunlight into usable electrical energy. The panel’s design optimizes light absorption and minimizes energy losses.

Mono PERC Solar Cells

The 72-cell configuration of Mono PERC solar cells enhances the panel’s efficiency by improving sunlight absorption, thus increasing energy output, making it ideal for diverse environmental conditions.

Durable Construction

Featuring robust construction with high transmission glass and an anodised frame, the panel provides durability, enabling it to combat harsh weather while maintaining energy output consistently.

Seamless Connectivity

Utilizing MC4 compatible connectors, the panel ensures hassle-free connectivity and integration into existing solar power systems, maintaining high performance through efficient power transfer.

Specifications

Model Name	E395M72-B
Rated Power at STC	395 Wp
Module Efficiency at STC	19.70%
Open Circuit Voltage (Voc)	49.10 V
Short Circuit Current (Isc)	10.21 A
Max Power Voltage (Vpm)	40.45 V
Max Power Current (Ipm)	9.75 A
Operating Temperature Range	-40°C to 85°C
Dimensions (L x W x H)	1993 mm x 1006 mm x 35 mm
Weight	23 Kg
Cable Length	1200 mm
Max. System Voltage	1500 V DC
